How to select SPD for power?
Tags:SPD How to select SPD for power? 2020-08-26 How to select SPD for power? 1074

For selection of power SPD, generally 3 points need to be considered.

1. The combination of SPD, which is determined by the power supply system.

There are 5 normally used power supplysystems, TN-S,TN-C,TN-C-S,TT and IT.

             How to select SPD for power?                        How to select SPD for power?

           How to select SPD for power?                        How to select SPD for power?

           How to select SPD for power?

Correspondence between power system and SPD combination

Single phase TN: 2P,1P+1

Single phase TT:1P+1

3 phase TN-S:4P,3P+1

3 phase TN-C、IT:3P

3 phase TT:3P+1

TN-C-S, former half is TN-C and the latter half is TN-S.


2.    Max. continuous operating voltage Uc

Uc is determined by the nominal opeating voltage of the power system Un. Uc must be higer than Un(Un is the voltage between line and neutual or between line and PE). Considering grid voltage fluctuation, Uc is generally required to be at least 1.15 times greater than Un, according to the local gird quality.


3.   Discharging capacity of SPD, which is determined by lightning protection level(importance) and lightning protection zone(location).
