GS8272-EX.MR RTD/TC,RS485,Relay Isolated Barrier(1 channel)

Temperature Input,relay,RS485 Output Isolated Barrier.transfer 4~20mA signal which linearly Transfer by thermal resistance or thermal couple in fidd from hazardous area to safe area isolatedly , at the same time,provide one channel of RS-485 bus output which based on MODBUS-RTU protaol and two channels of relay alarm output. input and output isolation.The product needs an independent power supply.

Number of channels:

1input/3outputs

Input signal:

PT100

Cu50

Cu100

RS-485 Output:

Involve

Relay alarm output:

Involve

Power Connection Mode:

Bus Power Supply

GS8272-EX.MR

Product details

Technichal Data

Download

click to consult

contrast

enquire

RTD/TC,RS485,Relay Isolated Barrier(1 channel)

Product Name	GS8272-EX.MR Isolated Barrier
Number of channels	1 input/1 output
Supply voltage(Ue)	20~35V DC
Input signal	Pt100;Cu50;Cu100;T;E;J;K;N;R;S;B
EX symbol	[Ex ia Ga]IIC
Weight	Approx 150g
Field apparatus	RTD;TC
