Low power SPD (24VDC; In=5kA ) 7029089
CZLB-24P  Low power SPD (24VDC; In=5kA ) 7029089
SPD for low power supply; 24VDC; IL:10A; C2: 10kV/5kA, D1: 1kA/line; 7.6mm thickness; grounded through DIN rail or terminal
voltage:
24VDC
Nominal discharge current ln:
5kA
CZLB-24P
Product details
Technichal Data
Download
contrast
enquire

Low power SPD (24VDC; In=5kA ) 7029089

Low power SPD (24VDC; In=5kA ) 7029089




Product Name  CZLB-24P Surge protective device
Nominal operating voltage Un  24VDC
Maximun continuous operating voltage Uc  36VDC
Nominal Discharge Current In(8/20us)  5kA
Maximun Discharge Current Imax(8/20us)  10kA
Protected Objects/Systems  24VDC

Low power SPD (24VDC; In=5kA ) 7029089

Low power SPD (24VDC; In=5kA ) 7029089

Low power SPD (24VDC; In=5kA ) 7029089

Low power SPD (24VDC; In=5kA ) 7029089

Low power SPD (24VDC; In=5kA ) 7029089


Product Features
Protections
Dimensions
Housing
Basic Parameter
Security Data(Lightning Protection)
Product Approvals
Certification
Standards
Ambient Requirements
Connection Parameters
Mounting
Generate PDF
Technichal Data
Product Features
Features 10kA; 7.6mm Ultra-thin; 24V DC
Protections
Protected Objects/Systems 24VDC
Dimensions
Depth 97.7mm
Height 92.4mm
Width 7.6mm
Housing
Brand Dinkle
Material PA66
Protection Level IP20
Flame Retardant Grade V0
Colors Gray
Basic Parameter
Nominal operating voltage Un 24VDC
Maximun continuous operating voltage Uc 36VDC
Nominal Operating Current IL 10A
Response Time 1ns
Number of Wires 2
Leakage Current <1uA
Security Data(Lightning Protection)
Nominal Discharge Current In(8/20us) 5kA
Maximum Discharge Current Imax(8/20us) 10kA
Total Discharge Current Itotal 20kA
Voltage Protection Level Up(8/20us) 600V(Line to Line)/1.0kV(Line to Ground)
Product Approvals
Certification Lightning Protection Certification
Certification
Explosion-Proof Certification N/A
Lightning Protection Certification Shanghai Lightning Protection Products Test Center
Standards
Names GB/T 18802.21 / IEC 61643-21; IEC 61508
Ambient Requirements
Ambient Temperature (Operation) ﹣40—70℃
Ambient Temperature (Storage) ﹣40—85℃
Permissible Humidity (Operation) 10%—90%
Applicable Location Cabinet
Maximum Altitude 2000m
Connection Parameters
Conductor Cross Section Solid 1.0—2.5mm2
Conductor Cross Section Flexible 1.0—2.5mm2
Stripping Length 8mm
Connection Method Terminal Connection
Maximum Tightening Torque 0.5Nm
Mounting
Mounting Position Cabinet
Mounting Method 35mm Lead Rail
Interface Screw
