Potentiometer,Isolated Barrier(1 channel)
GS8572-EX.R  Potentiometer,Isolated Barrier(1 channel)
Isolated barrier, converters thermal resistance, thermal couple, mV signal and potentiometer signal in hazardous area into 0/4~20mA or 0/1~5V signal. It is intelligent and has cold junction compensation function, RTD, TC, potentiometer indexing number and range can be configured through computer. The product should be supplied power independently. Input, output and power are each galvanically isolated.
Number of channels:
1input/1output
Input signal:
Potentiometer0-5kΩ
Potentiometer0-10kΩ
Output signal:
4~20mA
0~20mA
0~5V
1~5V
Power Supply Mode :
24VDC
Power Conntecion Mode:
Terminal Power Supply
Bus Power Supply
SIL Level:
SIL2
GS8572-EX.R
Product details
Technichal Data
Download
contrast
enquire

Potentiometer,Isolated Barrier(1 channel)

Potentiometer,Isolated Barrier(1 channel)


Product Name  GS8572-EX.R Isolated Barrier
Number of channels  1input/1output
Supply voltage(Ue)  20~35V DC
Input signal  Potentiometer
Output signal  0~20mA;4~20mA;0~5V;1~5V
Weight  Approx 150g
Field apparatus  Potentiometer

Potentiometer,Isolated Barrier(1 channel)

Potentiometer,Isolated Barrier(1 channel)


Potentiometer,Isolated Barrier(1 channel)

Potentiometer,Isolated Barrier(1 channel)


General
Input data
Output data
Power supply
Dimensions
Housing
Product approvals
Standard/Specification
Safe data(EX)
EMC data
Operating conditions
Connection data
Installation
Generate PDF
Technichal Data
General
Number of channels 1input/1output
Dielectric strength Non-intrinsically safe part and intrinsically safe part≥2500VAC,power supply part and non-intrinsically safe part≥500VAC
Temperature drift 0.01%F.S./℃
Response time Reach 90% of final value in 1s
Insulation resistance Non-intrinsically safe part and intrinsically safe part≥100MΩ,power supply part and non-intrinsically safe part≥100MΩ
Electromagnetic compatibility According to IEC 61326-1(GB/T 18268)
EX marking [Ex ia Ga]IIC
Weight Approx 150g
Field apparatus Potentiometer
Suitable location zone 0;zone 1;zone 2;IIA;IIB;IIC;T4~T6
Input data
Input signal Potentiometer
Output data
Output signal 0~20mA;4~20mA;0~5V;1~5V
Current output load resistance RL≤300Ω
Voltage output load resistance RL≥20kΩ
Alarm indication Lower than range, LED L falshing, output current ≈3.8mA;Higher than range, LED H falshing, output current ≈20.8mA;Breakage, LED L and H falshing at the same time, output current ≈20.8mA;Short circuit, LED L and H falshing at the same time, output current ≈3mA;
Power supply
Supply voltage(Ue) 20~35V DC
Power protection Reverse protection of power supply
Current consumption ≤40mA (at 24Vdc supply,20mA output)
Power supply mode Independent power supply
Power connecting mode DIN Rail BUS;Terminal
Dimensions
Depth 118.9mm
Height 106.0mm
Width 12.5mm
Housing
Brand Phoenix
Material PC
Degree of protection IP20
Flammability rating UL94/V0
Colour gray
Product approvals
Approvals NEPSI
Standard/Specification
NEPSI [Ex ia Ga] IIC Comply with standard: GB 3836.1、GB 3836.4、GB 3836.20
Safe data(EX)
Max. r.m.s. a.c. or d.c. voltage Um 250V
Max.output voltage Uo 8.5V(7,8,9,10)
Max.output current Io 20mA(7,8,9,10)
Max.output power Po 43mW(7,8,9,10)
IIC Max. external inductance Lo 3.6mH(7,8,9,10)
IIC Max. external capacitance Co 6.5μF(7,8,9,10)
IIB Max. external inductance Lo 10.8mH(7,8,9,10)
IIB Max. external capacitance Co 60μF(7,8,9,10)
IIA Max. external inductance Lo 28.8mH(7,8,9,10)
IIA Max. external capacitance Co 1000μF(7,8,9,10)
EMC data
Electrical fast transient/burst immunity According to:IEC 61326-3-1
Surge immunity According to:IEC 61326-3-1
Radiated,radio-frequency,electromagnetic field immunity According to:IEC 61326-3-1
Electrostatic discharge immunity According to:IEC 61326-3-1
Immunity to conducted disturbances, induced by radio-frequency fields According to:IEC 61326-3-1
Immunity to conducted, common mode disturbances in the frequency range 0 Hz to 150 kHz According to:IEC 61326-3-1
Operating conditions
Ambient temperature -20℃~+60℃
Storage temperature -40℃~+80℃
Relative humidity 10%~90%
Environmental requirements The air should not contain any medium corrupting the coat of chrome,nickel and silver.Moreover,violent quiver and impact or any cause of electromagnetic induction (such as big current or spark,etc.)must be avoided when using
Connection data
Conductor cross section solid range 0.5~2.5mm²
Conductor cross section flexible range 0.5~2.5mm²
Conductor cross section AWG min. 12
Conductor cross section AWG max. 24
Stripping length 8mm
Screw thread M3
Connection method Screw connection
Tightening torque min. 0.5 Nm
Tightening torque max. 0.6 Nm
Installation
Mounting type DIN35mm
