AO,Isolated Barrier(1 channel)
LBGS8067-EX  AO,Isolated Barrier(1 channel)
1input/1output,AO,Isolated Barrier.Field apparatus:2-wire valve positioner,electric converter.Input signal:0~20mA;4~20mA.Output signal:0~20mA;4~20mA;0~5V;1~5V.Supply voltage(Ue):20~35V DC.Approx 100g,Independent power supply.
Number of channels:
1input/1output
Input signal:
0/4~20mA
Output signal:
0/4~20mA
0/1~5V
Power Supply Mode:
24VDC
Power Connection Mode:
Terminal Power Supply
Special Function:
Surge protection function
LBGS8067-EX
Product details
Technichal Data
Download
contrast
enquire

AO,Isolated Barrier(1 channel)

AO,Isolated Barrier(1 channel)



Product Name
 LBGS8067-EX  Isolated Barrier
Number of channels  1input/1output
Supply voltage(Ue)  20~35V DC
Input signal  0~20mA;4~20mA
Output signal  0~20mA;4~20mA;0~5V;1~5V
Weight
 Approx 100g
Field apparatus
 2-wire valve positioner,electric converter


AO,Isolated Barrier(1 channel)AO,Isolated Barrier(1 channel)

AO,Isolated Barrier(1 channel)


General
Input data
Output data
Power supply
Dimensions
Housing
Product approvals
Standard/Specification
Safe data(EX)
EMC data
Operating conditions
Connection data
Installation
Generate PDF
Technichal Data
General
Number of channels 1input/1output
Dielectric strength Between non-intrinsically safe part and intrinsically safe part≥2500VAC,Between power supply part and non-intrinsically safe part≥500VAC
Output accuracy(20°C) 0.1%F.S.
Temperature drift 0.005%F.S./℃
Response time Reach 90% of final value in 3ms
Insulation resistance Non-intrinsically safe part and intrinsically safe part≥100MΩ,power supply part and non-intrinsically safe part≥100MΩ
Electromagnetic compatibility According to IEC 61326-1(GB/T 18268)
EX marking [Ex ia Ga]IIC
Weight Approx 100g
Field apparatus 2-wire Valve Positioner,Electric Converter
Suitable location zone 0;zone 1;zone 2;IIA;IIB;IIC;T4~T6
Input data
Input signal 0~20mA;4~20mA
Voltage drop ≤2V
Output data
Output signal 0~20mA;4~20mA;0~5V;1~5V
Current output load resistance RL≤750Ω
Voltage output load resistance RL≥20kΩ
Power supply
Supply voltage(Ue) 20~35V DC
Power protection Reverse protection of power supply
Current consumption ≤60mA (at 24Vdc supply,20mA output)
Power supply mode Independent power supply
Power connecting mode Terminal
Dimensions
Depth 114.5mm
Height 99.0mm
Width 22.5mm
Housing
Material PA
Degree of protection IP20
Flammability rating UL94/V0
Colour green
Product approvals
Approvals NEPSI
Standard/Specification
NEPSI [Ex ia Ga] IIC Comply with standard: GB 3836.1、GB 3836.4、GB 3836.20
Safe data(EX)
Max. r.m.s. a.c. or d.c. voltage Um 250V
Max.output voltage Uo 28V(9,10)
Max.output current Io 93mA(9,10)
Max.output power Po 651mW(9,10)
IIC Max. external inductance Lo 4.2mH(9,10)
IIC Max. external capacitance Co 0.083μF(9,10)
IIB Max. external inductance Lo 12.6mH(9,10)
IIB Max. external capacitance Co 0.65μF(9,10)
IIA Max. external inductance Lo 33.6mH(9,10)
IIA Max. external capacitance Co 2.15μF(9,10)
EMC data
Electrical fast transient/burst immunity According to:IEC 61326-1
Surge immunity According to:IEC 61326-1
Radiated,radio-frequency,electromagnetic field immunity According to:IEC 61326-1
Electrostatic discharge immunity According to:IEC 61326-1
Immunity to conducted disturbances, induced by radio-frequency fields According to:IEC 61326-1
Operating conditions
Ambient temperature -20℃~+60℃
Storage temperature -40℃~+80℃
Relative humidity 10%~90%
Environmental requirements The air should not contain any medium corrupting the coat of chrome,nickel and silver.Moreover,violent quiver and impact or any cause of electromagnetic induction (such as big current or spark,etc.)must be avoided when using
Connection data
Conductor cross section solid range Non-intrinsically safe part 0.5~2.5mm²;Intrinsically safe part 1.5~2.5mm²
Conductor cross section flexible range Non-intrinsically safe part 0.5~2.5mm²;Intrinsically safe part 1.5~2.5mm²
Conductor cross section AWG min. 12
Conductor cross section AWG max. 24
Stripping length 8mm
Screw thread M3
Connection method Screw connection
Tightening torque min. 0.5 Nm
Tightening torque max. 0.6 Nm
Installation
Mounting type DIN35mm
